Name: Coastal

Display Field: WATER_BODY_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This feature class was created using the OS boundary line High Water dataset, OS Open Map Local dataset and UKHO Open Data 3 nautical mile limit. The original data was created for the Water Framework Directive (2000/60/EC). Article 2, clause 7 of the WFD defines coastal waterbodies as ‘…a surface water on the landward side of a line, every point of which is at a distance of one nautical mile on the seaward side from the nearest point of the baseline from which the breadth of territorial waters is measured, extending where appropriate up to the outer limit of transitional waters’. Due to the large number of islands in Scotland, coastal waters were defined by territorial waters 3 nautical miles from the Mean High Water coastline covering all water within the 3 nautical mile territorial limit. Dataset includes the most recent overall classification information.

Service Item Id: f5ff5ffd387546d4860b9bf8acfebc93

Copyright Text: © Scottish Environment Protection Agency. Contains OS data Copyright Crown copyright [and database right].

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -302040.3164999997
YMin: 524068.46079999954
XMax: 475777.7806000002
YMax: 1225872.9404000007
Spatial Reference: 27700  (27700)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: OVERALL_CLASSIFICATION
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: High
  Label: High status / potential
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 112, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: Good
  Label: Good status / potential
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [152, 230, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: Good ecological potential
  Label: Good status / potential
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [152, 230, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: Moderate
  Label: Moderate status / potential
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 255, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: Moderate ecological potential
  Label: Moderate status / potential
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 255, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: Poor ecological potential
  Label: Poor status / potential
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [230, 152, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• AREA_KM2 ( type: esriFieldTypeDouble, alias: Area (km²) )
• PERIMETER_KM ( type: esriFieldTypeDouble, alias: Perimeter (km) )
• CATEGORY ( type: esriFieldTypeString, alias: Category, length: 20 )
• WB_ID ( type: esriFieldTypeString, alias: Water Body ID, length: 48 )
• WATER_BODY_ID ( type: esriFieldTypeInteger, alias: Water Body Id )
• EXPIRY_DATE ( type: esriFieldTypeString, alias: Expiry Date, length: 8000 )
• WATER_BODY_NAME ( type: esriFieldTypeString, alias: Water Body Name, length: 8000 )
• AREA_SQ_KM ( type: esriFieldTypeDouble, alias: Area Sq Km )
• RBD_CODE ( type: esriFieldTypeInteger, alias: Rbd Code )
• RIVER_BASIN_DISTRICT ( type: esriFieldTypeString, alias: River Basin District, length: 8000 )
• SBD_CODE ( type: esriFieldTypeInteger, alias: Sbd Code )
• SUB_BASIN_DISTRICT ( type: esriFieldTypeString, alias: Sub Basin District, length: 8000 )
• HEAVILY_MODIFIED ( type: esriFieldTypeString, alias: Heavily Modified, length: 8000 )
• ARTIFICIAL ( type: esriFieldTypeString, alias: Artificial, length: 8000 )
• GENRE ( type: esriFieldTypeString, alias: Genre, length: 8000 )
• HMAWB_REASON ( type: esriFieldTypeString, alias: Hmawb Reason, length: 8000 )
• EASTING ( type: esriFieldTypeInteger, alias: Easting )
• NORTHING ( type: esriFieldTypeInteger, alias: Northing )
• REPORTING_LATITUDE ( type: esriFieldTypeDouble, alias: Reporting Latitude )
• REPORTING_LONGITUDE ( type: esriFieldTypeDouble, alias: Reporting Longitude )
• TEAM ( type: esriFieldTypeString, alias: Team, length: 8000 )
• STATUS_RISK_ASSESSMENT ( type: esriFieldTypeString, alias: Status Risk Assessment, length: 8000 )
• NO_DET_RISK_ASSESSMENT ( type: esriFieldTypeString, alias: No Det Risk Assessment, length: 8000 )
• LESS_THAN_GOOD ( type: esriFieldTypeString, alias: Less Than Good, length: 8000 )
• CLASSIFICATION_YEAR ( type: esriFieldTypeInteger, alias: Classification Year )
• CURRENT_YEAR ( type: esriFieldTypeString, alias: Current Year, length: 8000 )
• CLASS_DS_URL ( type: esriFieldTypeString, alias: Class Ds Url, length: 8000 )
• CERTAINTY ( type: esriFieldTypeDouble, alias: Certainty )
• CERTAINTY_BAND ( type: esriFieldTypeString, alias: Certainty Band, length: 8000 )
• OVERALL_CLASSIFICATION ( type: esriFieldTypeString, alias: Overall Classification, length: 8000 )
• TARGET_CLASS ( type: esriFieldTypeString, alias: Target Class, length: 8000 )
• TARGET_CLASS_NO_DET ( type: esriFieldTypeString, alias: Target Class No Det, length: 8000 )
• WISE_CODE ( type: esriFieldTypeString, alias: Wise Code, length: 8000 )
• ECO_REGION ( type: esriFieldTypeInteger, alias: Eco Region )
• DATA_SOURCE ( type: esriFieldTypeString, alias: Data Source, length: 8000 )
• COASTAL_TYPOLOGY ( type: esriFieldTypeString, alias: Coastal Typology, length: 8000 )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )
• Shape_Area ( type: esriFieldTypeDouble, alias: Shape_Area )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
